LD 2 Containers

DPE Containers | DPN Containers

LD 2 Containers, ULD 2, DPE Containers, DPE ULD, DPN ULD, LD 2 Air Cargo Containers

A half-width Air Cargo Container, commonly used in certified lower hold compartments of 747, 767, 777 and 787 aircraft.

DPE & DPN ULD Air Cargo Containers

An ageless and classic element of the Air Cargo market is the LD 2 Containers, additionally referred to as DPE and DPN ULD's. The LD 2 Air Cargo Containers feature a solitary single piece polymer shell, which offers a significant decrease of maintenance costs as well as down time, as the rotationally molded body provides premium durability over archaic technology, such as light weight aluminum, polycarbonate as well as fiberglass. The polymer shell is also available in a wide array of colors, including custom-matched shades for branding, marketing or for easy recognition and improved procedures performance during custom critical applications, such as peak season.

Featuring lighter tare weights than most, the LD 2 units offer a direct savings in fuel consumption, carbon credits (where applicable) and lowest total cost of ownership.



LD 2 DPE Air Cargo Container

Click on any of the thumbnail images below to display the larger image in the LD 2 DPE Container Image Gallery.

LD 2 Air Cargo Container

LD 2 DPE Air Cargo Container
LD 2 Container, ULD 2, LD 2 Air Cargo, Air Cargo Container, ULD Container, DPE Container
DPE Container, Air Cargo Container base, Hybrid Polymer Aluminum ULD Container, LD 2 Air Cargo Container
LD 2, DPE Container, DPE ULD Container, LD 2 ULD, Granger Aerospace LD 2, Air Cargo LD 2
LD 2 Air Cargo Container, LD 2 Air Freight Container, ULD 2 DPE, DPE ULD Container, IATA LD 2, LD 2 Air Cargo
LD 2 Air Cargo Container, LD 2 Air Freight Container, ULD 2 DPE, DPE ULD Container, IATA LD 2, LD 2 Air Cargo



LD 2 DPE Technical Specifications

Technical Specifications
TSO   N/A
IATA   LD-2/DPE
Spec.   AS 1677
Granger Aerospace P/N   GA2-0102-2
Base size 1534 mm x 1562 mm 60.4 in x 61.5 in
Height 1625 mm 64 in
Roof length 1562 mm 61.5 in
Max. gross weight 1224 kg 2700 lb
Internal volume 3.5 cu m 123 cu ft
Door opening 1010 mm x 1480 mm 39.75 in. x 58.25 in
Tare weight from 72.1 kg 159 lb



LD 2 DPE Features:

  • Granger Aerospace Products Air Cargo Containers are the only cargo container manufactured from a combination of aluminum and durable LLDPE.
  • The LD-2 Body is weld-able
  • The Granger Aerospace Products Air Cargo Container is lighter than most standard containers.
  • Granger Aerospace Products cargo containers are robust.
  • No aluminum body panels to patch.
  • No aluminum body frames to replace.
  • Lighter weight, less down time and lower repair costs equals lower cost of ownership.
  • Enhanced Threshold.
  • Fewer fasteners to replace.
  • Unique design allows for faster repairs.
  • Less spare parts to keep in stock.
  • Granger Aerospace Products offers alternative solutions for your ULD needs.
  • It is our goal to offer our customer not only lower cost container but a trusted partnership for your company.
  • It’s our goal to offer more choices to our customers
  • Through or focus on technology and research, we are continually making improvements to our design.
  • Our customers save fuel by using robust as well as cost-efficient lightweight containers.


    • LD 2 DPE Dimensional Drawings

    Click below to download LD 2 DPE Dimensional PDF
    LD 2 Dimensions, LD 2 Air Cargo Container Dimensions, DPE dimensions




    LD 2 DPN Air Cargo Container

    Click on any of the thumbnail images below to display the larger image in the LD 2 DPN Container Image Gallery.

    LD 2 Air Cargo Container

    LD 2 DPN Air Cargo Container
    DPN Air Cargo Container, LD 2 Container, ULD 2, LD 2 Air Cargo, Air Cargo Container, ULD Container, DPN Container
    DPN Container,DPN Air Cargo Container, Air Cargo Container base, Hybrid Polymer Aluminum ULD Container, LD 2 Air Cargo Container
    LD 2, DPN Container, DPN ULD Container, LD 2 ULD, Granger Aerospace LD 2, Air Cargo LD 2
    LD 2 Air Cargo Container, LD 2 Air Freight Container, ULD 2 DPN, DPN ULD Container, IATA LD 2, LD 2 Air Cargo
    LD 2 Air Cargo Container, LD 2 Air Freight Container, ULD 2 DPN, DPN ULD Container, IATA LD 2, LD 2 Air Cargo



    LD 2 DPN Technical Specifications

    Technical Specifications
    TSO   N/A
    IATA   LD-2/DPN
    NAS Specification   AS 1677
    Granger Aerospace P/N   GA2-0102-3
    Base size 1534 x 1562 mm 60.4 in x 61.5 in
    Height 1625 mm 64.0 in
    Roof length 1562 mm 61.5 in
    Max. gross weight 2449 kg 2700 lb
    Internal volume 3.3 cu m 114 cu ft
    Door opening 1009 x 1480 mm 39.75 in x 58.25 in
    Tare weight from 104.3 kg 230 lbs.

    LD 2 DPN Dimensional Drawings

    Click below to download LD 2 DPN Dimensional PDF
    LD 2 Dimensions, LD 2 Air Cargo Container Dimensions, DPN dimensions

    LD 2 DPN Features:

  • Granger Aerospace Products Air Cargo Containers are the only cargo container manufactured from a combination of aluminum and durable LLDPE.
  • The LD-2 Body is weld-able
  • The Granger Aerospace Products Air Cargo Container is lighter than most standard containers.
  • Granger Aerospace Products cargo containers are robust.
  • No aluminum body panels to patch.
  • No aluminum body frames to replace.
  • Lighter weight, less down time and lower repair costs equals lower cost of ownership.
  • Enhanced Threshold.
  • Fewer fasteners to replace.
  • Unique design allows for faster repairs.
  • Less spare parts to keep in stock.
  • Granger Aerospace Products offers alternative solutions for your ULD needs.
  • It is our goal to offer our customer not only lower cost container but a trusted partnership for your company.
  • It’s our goal to offer more choices to our customers
  • Through or focus on technology and research, we are continually making improvements to our design.
  • Our customers save fuel by using robust as well as cost-efficient lightweight containers.

    • LD 2 Air Cargo Container Links


    LD 2 DPE/DPN
    Air Cargo Container
    Information

    Click below to download LD 2 DPN Technical PDF
    LD 2 Specifications, Dimensions, LD 2 Air Cargo Container Dimensions, DPE Dimensions, DPN dimensions

    Air Cargo Containers

    Granger ULD Features

    ULD Single Piece Poly Shell, ULD Container, Single Piece ULD Shell, ULD Body, Air Cargo Container body

    Durable Single Piece Poly Shells

    Granger's innovative single piece polymer shell produces incredible strength and durability which leads to a reduction in maintenance with a significantly reduced number of fasteners. The reduced number of replacement parts aides in reduced inventories and reduced overheads, thus increasing profits. Fly your containers longer with Granger Aerospace ULDs!

    ULD Construction, ULDs, Air Cargo containers, Poly Air Cargo Containers, Aluminum Air Cargo Containers

    PoLYMER/Aluminum Construction

    High strength aluminum base designed to handle baggage, heavy cargo and to withstand the rigorous daily operations of commercial airlines, cargo operations, small package sort facilities and much more! Strength of aluminum combined with futuristic polymer durability!

    Color Air Cargo Container, ULD Container Color, Custom Color Air Cargo Container, Custom ULD container

    Stand out from the Competition

    In todays fast moving, ever changing markets, we all have to stand out from our competition. Take your marketing and branding to the next level with custom color ULD Containers from Granger Aerospace! Improve inventory tracking and tarmac efficiences by easily identifying your containers with custom color ULD Containers from Granger Aerospace!

    Granger.aero

    ULD Container being loaded, ULD Container, Air Cargo Container being Loaded, Air Freight Container being loaded, ULD Container going onto a plane

    Innovative design features

    Robust, Durable and innovative

    Granger Plastics Company has been involved in the production of certified, airworthy, Air Cargo Containers as well as ULD containers for over 20 years.

    Granger's high quality production and industry proficiency helped direct the decision for Granger to introduce, Granger Aerospace, A Division of Granger Industries focused on providing solutions for the Aerospace and Defense sectors. This decision enabled Granger Plastics to work towards obtaining it's extremely lauded TSO C90d accreditation from the FAA.
